ADO System® IDC technology

The fastest and most reliable connection technology

The ADO system® technology based on Insulation displacement (IDC) technology offers significant productivity savings as well as secure and reliable connection

Main benefits

• Boosted  productivity thanks to ADO System® technology that reduces
  wiring time by up to 80% compared to screw clamp connection
• Improved reliability of installation :  Elimination of wiring mistakes thanks to the locking of tool during connection process and no conductor preparation
• Reduced fatigue : the automatic tool allow smooth and no effort wiring
• Service continuity ensured even in severe environments thanks to  vibration
   and corrosion proof connection
• Saved space in cabinets thanks to high density wiring (up to 2 wires per clamp)
• Protection against unwanted manouvers: tools is needed to make wiring changes

Main features

• Connecting capacity from 0.22 to 4 mm² (24 to 12 AWG)
• Technologies : hybrid ADO/screw clamp and ADO/ADO terminal blocks
• Gas-tight connection
• Maintenance free screwless connection
• "C" shape jaw allow permanently balanced contact forces

Download ADO system® IDC Technology Catalog
