DC Converter

This line is designed for all non-industrial applications: isolated and non-isolated power supply units/converters, able to supply input-output voltages equal to or different from rated input voltage. Their primary function is to compensate fluctuations in input voltage and maintain a stable output. They can be supplied DIN Rail Mountable or not, all have short-circuit and overload protection on output and guarantee a stable output voltage. Like all Adel system products they comply with the latest standards applied to the industry.

------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Non-isolated DC/DC STEP-UP Unit

Non-isolated DCDC STEP-UP Unit

Main features:

Input: 12 Vdc
Output: 24 - 30 - 40 - 48 - 60 Vdc
Output In: 3 A ÷ 6 A
Adjustable output ±10%
Ambient temperature operation field: 0 - 50° C
IP20

The low voltage power supplies/converters in the STEP-UP range are suitable for producing voltages higher than the input voltage. They are typically used for currents of 3-6A, in cases where there is a rated input voltage of 12Vdc transformed into higher output voltage, perhaps to connect to a 12Vdc battery to then power a 24Vdc PLC. STEP-UP units feature switch-mode technology, are DIN Rail Mountable, and have output short-circuit and overload protection. For use in industrial and automotive applications, they are particularly reliable, robust, easy to use and comply with the latest regulatory standards.

SUP Isolated DC/DC Converters

SUP Isolated DCDC Converters
